Publication 2711-UM014B-EN-P
Configuring the Terminal 3-15
EtherNet/IP Communications
The EtherNet/IP screen lets you display or modify some of the
EtherNet/IP communication settings for an Ethernet PanelView
terminal.
Additional parameters (Gateway Address, DNS Server and Domain
Name, and Timeout values) are set in the Communications Setup
dialog of the PanelBuilder32 software and downloaded with the
application.
DHCP/BootP Enable
DHCP/BootP Enable (Dynamic Host Configuration Protocol)
automatically allocates network devices and configurations to newly
attached devices on a TCP/IP network. When DHCP/BootP Enable is
enabled, the PanelView terminal is automatically assigned an IP
Address and Subnet Mask. These fields will be read only. Select
disable to manually enter an IP Address or Subnet Mask for the
PanelView terminal.
IMPORTANT
Settings downloaded with an EtherNet/IP application
have priority over terminal settings and take effect
immediately after the download.
IMPORTANT
If DHCP/BootP is enabled in the downloaded
application and then disabled on the terminal, the
terminal will not have the necessary information
(Gateway Address, IP address, Subnet Mask) to
connect to the network on a restart. The Gateway
Address cannot be entered at the the terminal; you
must configure this address in the Communication
Setup dialog of PanelBuilder32.
DHCP/BootP Enable:
F16
EXIT
Terminal
Restart
F1
EtherNet/IP
Enabled
Subnet Mask:
Interscan Delay F3:
100
Ethernet Address: ##:##:##:##:##:##:##
Comms
Status
Attached
ms
EXIT
IP Address:
131.200.55.30
255.255.255.0
FW Revision: ######## Serial #: ########
