Allen-Bradley Rockwell Automation PowerFlex 700 Series User Manual

26 Rockwell Automation Publication PFLEX-AP005B-EN-P - May 2019
Chapter 1 Drive Selection Considerations
Figure 9 - PowerFlex 700 Frames 8 and 9 (IP00) to PowerFlex 750-Series Frame 7
(IP00)
Dimensions mm (in.)
Drive Frame A B C D E F G H
700 8 and 9 757.7 (29.83) 614.4 (24.19)
599.4 (23.60)
(1)
726.4 (28.60)
(2)
781.8 (30.78)
(3)
2373.9 (93.46) 1524.0 (60.0) 463.8 (18.26) 345.4 (13.6)
(1)
345.4 (13.6)
(2)
400.8 (15.8)
(3)
599.4 (23.6)
(1)
726.4 (28.6)
(2)
781.8 (30.8)
(3)
750-Series 7 430.0 (16.93) 380.0 (14.96) 349.6 (13.76) 881.5 (34.7) 838.0 (33.0)
(1) For PowerFlex 700 drive catalog numbers 20Bx365…20Bx481.
(2) For PowerFlex 700 drive catalog numbers 20Bx535 and 20Bx600.
(3) For PowerFlex 700 drive catalog number 20Bx730.
C
A
B
E
D
TB11
TE
25 AMPERES RMS
MAXIMUM
RISK OF SHOCK
REPLACE AFTER
SERVICING
!
DANGER
DANGER
RISK OF SHOCK
REPLACE AFTER
SERVICING
!
DANGER
TB9
8 AMPERES RMS
MAXIMUM
DC+
V
W
U
R S T DC-DC+
GND
C
A
B
D
HG
E
F
PowerFlex 700 Frames 8 and 9
(IP00, NEMA/UL Type Open)
PowerFlex 750-Series Frame 7
(IP00, NEMA/UL Type Open)
