Rockwell Automation Publication PFLEX-AP005B-EN-P - May 2019 31
Drive Selection Considerations Chapter 1
Table 13 - PowerFlex 700 Drives Power Terminal Block Locations (continued)
Refer to pages 32 and 33 for typical locations.
Location
No. Name Frame Description
Wire Size Range
(1)
Torque
Maximum Minimum Maximum Recommended
4 I/O Terminal
Block
0…6 Signal and control connections 2.5 mm
2
(14 AWG)
0.30 mm
2
(22 AWG)
0.6 N•m
(5.3 lb.•in.)
0.6 N•m
(5.3 lb.•in.)
7…10 4.0 mm
2
(12 AWG)
0.049 mm
2
(30 AWG)
0.6 N•m
(5.3 lb.•in.)
0.6 N•m
(5.3 lb.•in.)
5 Encoder Terminal
Block
0…10 Encoder power and signal connections 0.75 mm
2
(18 AWG)
0.196 mm
2
(24 AWG)
0.6 N•m
(5.3 lb.•in.)
0.6 N•m
(5.3 lb.•in.)
6 Fan Terminal
Block
5…6 User supplied fan voltage 4.0 mm
2
(12 AWG)
0.5 mm
2
(22 AWG)
0.6 N•m
(5.3 lb.•in.)
0.6 N•m
(5.3 lb.•in.)
7 4.0 mm
2
(12 AWG)
0.5 mm
2
(22 AWG)
0.9 N•m
(8.0 lb.•in.)
0.6 N•m
(5.3 lb.•in.)
8…10 4.0 mm
2
(12 AWG)
0.5 mm
2
(22 AWG)
0.6 N•m
(5.3 lb.•in.)
0.6 N•m
(5.3 lb.•in.)
(1) Maximum/minimum sizes that the terminal block will accept—these are not recommendations.
Terminal Description Notes
BR1
BR2
DC Brake (+)
DC Brake (–)
DB Resistor Connection
Important: Only one DB resistor can be used with Frames 0…3.
Connecting an internal and external resistor could cause
damage.
DC+ DC Bus (+) DC input/brake connections
DC– DC Bus (–)
PE PE Ground
PS+ Auxiliary Control
Terminal Block
See page 32
.
PS–
Motor Ground
U U (T1) To motor
VV (T2)
WW (T3)
R R (L1) AC line input power
Three-phase = R, S and T
Single-phase = R and S only
(1)
SS (L2)
T T (L3)
(1) Frames 0…7 only.
