22 SLC 500™ Analog I/O Modules
Publication 1746-IN008A-US-P
Specifications
General Specifications for NI4, NIO4I, NIO4V, NO4I,
NO4V, FIO4I, FIO4V
Description Specification
SLC Communication Format 16-Bit Two’s Complement Binary
Field Wiring to Backplane Isolation 500V dc
Update Time 512 µs for all channels in parallel
Recommended Cable Shielded Belden #8761
Maximum Wire Size #14 AWG (maximum)
Terminal Block Removable
Location 1746 chassis
Calibration
Factory Calibrated
(1)
(1) See the customer calibration program and procedure in the SLC 500 Fast Analog I/O Modules
User Manual, publication number 1746-6.9.
Noise Immunity NEMA Standard ICS 2-230
Environmental Conditions
Operating Temperature
Storage Temperature
Relative Humidity
0
° to +60° C (+32° to +140° F)
-40
° to +85° C (-40° to +185° F)
5 to 95% (non-condensing)
Agency Certification
(when product or packaging is marked)
• CSA certified
• Hazardous Location Class I, Division 2
Groups A, B, C, D certified
• UL listed
• CE marked for all applicable directives
