allen HP205 - Engine Specifications

064355 - 06/2017
Page 13
Engine Specications
37 HP Kohler
Model Command PRO EFI ECH980
Power hp(kW) 1 37 (27.6)
Displacement cu in (cc) 61 (999)
Bore in (mm) 3.5 (90)
Stroke in (mm) 3.1 (78.5)
Peak Torque lbs. ft (Nm) 58 (78.6)
Compression Ratio 8.8:1
Dry Weight lbs (kg) 132 (60)
Oil Capacity U.S. quarts (L) 2 (1.9)
Lubrication Full pressure w/full-ow lter
Dimensions L x W x H in 15.8 x 19.1 x 23.6
Backpressure Limit 40
Rated Speed (RPM) 3600
