allen HP205 - Seat Frame Assembly

064355 - 06/2017
Page 44
SECTION 4
PARTS
Seat Frame Assembly
Illustration
PARTS LIST
QTYDESCRIPTIONPART NO.
ITEM
4
FSTN, 1/4-20 HHCS X 3/4
0100021
4
FSTN, HHCS 3/8-16 X 1/2
0100342
12
FSTN, HHCS 3/8-16 X 1
0100363
1
FSTN, FW 1/4
0100814
4FSTN, LW 1/4010089
5
4FSTN, LW 3/80100916
12FSTN, NUT NYLOK 3/8-16010464
7
8FSTN, FW HARD A325 3/8 (p)0177518
1
FSTN, NUT STOVER LOCK 1/4-20
0205429
1
PIVOT, THROTTLE CABLE
02498410
1
CABLE, THROTTLE 52" HD
02824311
4
FSTN, NUT HEX 1/4-20 NYLOC
02967112
1
ROCKER SWITCH
0
3212513
8FSTN, CLIP TINNERMAN 1/4-2003932914
1CUP HOLDER04153715
13FSTN, SFBHCS 1/4"-20 x 3/404234316
4
PAL NUT- 1/4-2004754617
1
LOCKING CONTROL, QUADRASTAT (Q14020)
04764318
3RUBBER BUMPER04766519
1
FEMALE RECEPTICAL 12VDC
04958820
1
PROP F/ SEAT FRAME
05321122
1
DECAL, 13.35" X 8" ALLEN OVAL
05633923
1DECAL ALLEN OVAL 4" X 6.67" WHITE05634024
1SEAT, RIDER06137225
1ARM RESTS FOR SEAT06137326
2METER, TACH/HOUR INDUCTI
VE, F/EFI06438627
1
JOYSTICK, LH HDX760/HP205
06451028
1
JOYSTICK, RH HDX760/HP205
06451129
1
SEAT FRAME WMNT
06457730
1
CLUTCH GUARD ASSEMBLY
06458831
1
FRONT SCREEN ASSEMBLY
06462032A
-
HANDLE, LOAD RATED NYLON
04867832B
1LIGHT, LED06474933
1WARRANTY DECAL, 2 YR, SIZE 2.5 INCH06483834
2COVER PLATE06492735
1
EPA LABEL, 2017, AEC
06590836
2
DECAL, PINCH POINT
06591737
1
DECAL, SINGLE POINT LIFT HP205
06606638
1
DECAL, HAND TOOL
HP205
06606839
1
DECAL, FUSE BOX HP205
06606940
1
DECAL, CRUISE HP205
06607141
1DECAL, LH STRIPE HP20506607342
1DECAL, RH STRIPE HP20506607443
2HEAT SHIELD066076
44
1TANK, VENT X106613045
1
CAP, FILLER BREATHER SPB-S-1-10-N04
04788667
26
25
28
15
27
30
41
42
18
16
32A
23
44
2
6
3
7
13
34
39
35
29
If you remove the seat, you must use
grade 8 bolts when replacing
