allen HP205 - Page 45

064355 - 06/2017
Page 45
SECTION 4
PARTS
Seat Frame Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010002 FSTN, 1/4-20 HHCS X 3/4 4
2 010034 FSTN, HHCS 3/8-16 X 1/2 4
3 010036 FSTN, HHCS 3/8-16 X 1 12
4 010081 FSTN, FW 1/4 1
5 010089 FSTN, LW 1/4 4
6 010091 FSTN, LW 3/8 4
7 010464 FSTN, NUT NYLOK 3/8-16 12
8 017751 FSTN, FW HARD A325 3/8 (p) 8
9 020542 FSTN, NUT STOVER LOCK 1/4-20 1
10 024984 PIVOT, THROTTLE CABLE 1
11 028243 CABLE, THROTTLE 52" HD 1
12 029671 FSTN, NUT HEX 1/4-20 NYLOC 4
13 032125 ROCKER SWITCH 1
14 039329 FSTN, CLIP TINNERMAN 1/4-20 8
15 041537 CUP HOLDER 1
16 042343 FSTN, SFBHCS 1/4"-20 x 3/4 13
17 047546 PAL NUT- 1/4-20 4
18 047643 LOCKING CONTROL, QUADRASTAT (Q14020) 1
19 047665 RUBBER BUMPER 3
20 049588 FEMALE RECEPTICAL 12VDC 1
22 053211 PROP F/ SEAT FRAME 1
23 056339 DECAL, 13.35" X 8" ALLEN OVAL 1
24 056340 DECAL ALLEN OVAL 4" X 6.67" WHITE 1
25 061372 SEAT, RIDER 1
26 061373 ARM RESTS FOR SEAT 1
27 064386 METER, TACH/HOUR INDUCTIVE, F/EFI 2
28 064510 JOYSTICK, LH HDX760/HP205 1
29 064511 JOYSTICK, RH HDX760/HP205 1
29 061373 ARM REST, RIDER SEAT RH 1
30 064577 SEAT FRAME WMNT 1
31 064588 CLUTCH GUARD ASSEMBLY 1
32A 064620 FRONT SCREEN ASSEMBLY 1
32B 048678 HANDLE, LOAD RATED NYLON -
33 064749 LIGHT, LED 1
34 064838 WARRANTY DECAL, 2 YR, SIZE 2.5 INCH 1
35 064927 COVER PLATE 2
36 065908 EPA LABEL, 2017, AEC 1
37 065917 DECAL, PINCH POINT 2
