allen HP205 - LH Gearbox Assembly

064355 - 06/2017
Page 68
SECTION 4
PARTS
LH Gearbox Assembly
Illustration
PARTS LIST
U/MQTYDESCRIPTIONPART NO.
ITEM
8
FSTN, HHCS 1/2-13 X 1-1/4 GR 5
0100681
8FSTN, HHCS 1/2-13 X 1-1/2 GRADE 80100692
8FSTN, HHCS 1/2-13 X 2-1/4 GR 50100713
24FSTN, LW 1/2 GR80100934
3PLUG, 3/4 NPTF BI SQ HD PIPE0129535
3SCR, 10-24x1/2 RDH PPH0134846
3
FSTN, LW STAR #10
0137407
1
GAUGE, 3/4-14 NPT PORTHOLE VIEW
0156728
1
O-RING, 15/16x1-3/16x1/8 BUNA
0156739
1FITTING, 1/4-28 NPT 45
° GREASE01851010
2SEAL, Ø1.375 RADIAL SHAFT OIL02917911
1
SEAL, Ø1.875 RADIAL SHAFT OIL
02918012
1VALVE, RELIEF 1/8-27NPT (AIR V)02952913
2
RING, RETAINING Ø2.4780
03271414
1
RING, Ø2.857 RETAINING
03271515
1
CASE, GEARBOX 600 SERIES
04154616
1
FAN, 600 SERIES GEARBOX
04157817
1COVER, FAN 600 SERIES GEARBOX04157918
1COVER, TOP ASSEMBLY 600 SERIES04158019
1COVER, BOTTOM ASSEMBLY 600 SERIES04158120
2CAP, FLA
NGE ASSEMBLY 600 SERIES04158321
1GEARBOX RING WMNT06122222
1SHAFT/GEAR ASSBMELY, LH GEAR, RH THRDS06461123
1
WORM SHAFT ASSEMBLY, LH WORM
06461624
2
4
10
19
26
28
28
19
5
23
25
27
23
22
3
4
24
21
11
14
21
4
1
17
18
7
6
1
4
20
16
8
9
13
5
