Page 67
SECTION 4
PARTS
Spray System Assembly (cont’d)
Parts List
ITEM PART NO. DESCRIPTION QTY
1 047700 TANK, 6 GALLON WATER PLASTIC 1
2 048921 STRAP, TANK MSP425 8
3 048246 HOSE 3/8” WATER LINE
4 048652 TEE, PLASTIC 1/4 x 1/4 x 1/4 1
5 049957 NOZZLE BODY MALE STRAIGHT CP8028-NYB 2
6 041624 RETAINER, NYLON SPRAY TIP 2
7 065244
STRAINER, POLY 100 µ MESH, W/ CHECK
VALVE
2
8 012702 TIP, 80°x0.10 GPM BRASS SPRAY 2
9 065175 CHECK VALVE F/ SPRAY SYSTEM 2
10 048653 BARB, HOSE PLASTIC 1/4" x 1/4 NPT 3
