allen HP205 - Left Rotor Module Assembly

064355 - 06/2017
Page 54
SECTION 4
PARTS
LH Rotor Module Assembly
Illustration
DETAIL A
SCALE .57
A
34
37
32
12
57
PARTS LIST
QTYDESCRIPTIONPART NO.
ITEM
24
FSTN, HHCS 5/16-18 X 2 GR 5
0100242
8
FSTN, HHCS 3/8-16 X 1
0100363
4
FSTN, HHCS 3/8-16 X 1 3/4" LONG GR8
0100394
1
FSTN, FW 7/16
010084
5
2
FSTN, FW 3/4
0100876
24FSTN, LW 5/160100908
8FSTN, LW 3/80100919
2FSTN, LW 7/1601009210
4
FSTN, NUT HEX 3/4-1001011211
2
RING,
Ø7/16 E-STYLE RETAINING
01567712
1
FSTN, SHCS 1/2-13 X 1-1/2 RH
01569113
1
PLUG, PLASTIC CAP EC12
01569314
6
PLUG W-1 RED PLASTIC TAPERD
01569415
4
FSTN, FW HARD A325 3/8 (p)
01775116
8FSTN, LW 3/401809717
4FSTN, NUT STOVER LOCK 3/8-1602051418
1FSTN, JAM HEX NUT 5/8-18 RH02068819
6FSTN, 3/8 SHOULDER BOLTx1/2 LONG02509120
6
BUSHING, 3/8x1/2x5/16 BRONZE
02509221
1
KEY, 1/4 X 3 1/8" LONG, HARD
02699222
1
FSTN, HHCS 5/8-18 X
2 GR 8
02796923
4
FSTN, HHCS, 3/4-10 X 1 1/4" LONG
04254725
2
FSTN, NUT STOVER 5/8-18
04326926
2FSTN, NYLON NUT 3/4-1004412927
2FTG, F6400-4-6-O STR JIC-SAE04592228
1FSTN, HHCS 5/8-18x2-1/4 GR8 YZPLT04735429
6BLADE, 8 X 23 FLAT FINISH04797330
1
ORIFICE, FOR L/R STEERING CYL CFJ4-043
04838531
1
PIN, YOKE ARM
04862832
1
PITCH CYLINDER HDX SERIES 3" BORE 1 1/2" STROKE
04865933
1
PLATE, PRESSURE 6 BOSS HDX740
04953734
1
SPIDE
R ASSEMBLY, RH HDX740
04953935
1STABILIZER RING HDX74004954336
1BEARING CAP HDX74004959937
1BEARING HDX740 SPIDER ASSEMBLY04969738
1WASHER, HD RETAINING04970839
1
KEY, HDX740 ROTOR
05070040
1
KEY, 3/16 X 1/4 X 2
05322341
1
THROTTLE BRKT
05338542
2
FSTN, HHCS 3/4-10 X 1 3/4" GR. 8 YELLOW ZINC
05538043
1
SPACER F/ CLUTCH, MSP445
05561644
4FSTN, FW 3/4" GRADE 8 YELLOW ZINC05977645
2BEARING ASSEMBLY FOR HP20506625346
1WASH
ER, LARGE OD060865
47
1HHCS, 7/16-20 X 3/406087048
1
ROD END
06123449
1
BELT, CVT
06393050
1
SCR, 7/16-20x4-1/2 YZ GR 8 HHC
06457451
2
STUD, 3/4-10 X 4
06459252
1
GEARBOX ASSEMBLY, RH
06461353
1ENGINE MNT, GEARBOX HOUSING06465554
1CYL MNT PLATE WMNT, LH064659
55
1CROSSHEAD, 2-WAY06466456
1PITCH YOKE ARM FOR HP205065116
57
1
ENGINE, KOHLER ECH980
06582558
1MUFFLER, LH06587559
1PULLEY, HP205, DRIVER06596760
1PULLEY, HP20506610
761
1
LOWER BELT GUARD
064591101
36
30
15
2
8
33
49
19
20
21
58
46
3
9
56
54
53
34
32
12
35
25
17
31
