allen HP205 - Page 55

064355 - 06/2017
Page 55
SECTION 4
PARTS
LH Rotor Module Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
2 010024 FSTN, HHCS 5/16-18 X 2 GR 5 24
3 010036 FSTN, HHCS 3/8-16 X 1 8
4 010039 FSTN, HHCS 3/8-16 X 1 3/4" LONG GR8 4
5 010084 FSTN, FW 7/16 1
6 010087 FSTN, FW 3/4 2
8 010090 FSTN, LW 5/16 24
9 010091 FSTN, LW 3/8 8
10 010092 FSTN, LW 7/16 2
11 010112 FSTN, NUT HEX 3/4-10 4
12 015677 RING, Ø7/16 E-STYLE RETAINING 2
13 015691 FSTN, SHCS 1/2-13 X 1-1/2 RH 1
14 015693 PLUG, PLASTIC CAP EC12 1
15 015694 PLUG W-1 RED PLASTIC TAPERD 6
16 017751 FSTN, FW HARD A325 3/8 (p) 4
17 018097 FSTN, LW 3/4 8
18 020514 FSTN, NUT STOVER LOCK 3/8-16 4
19 020688 FSTN, JAM HEX NUT 5/8-18 RH 1
20 025091 FSTN, 3/8 SHOULDER BOLTx1/2 LONG 6
21 025092 BUSHING, 3/8x1/2x5/16 BRONZE 6
22 026992 KEY, 1/4 X 3 1/8" LONG, HARD 1
23 027969 FSTN, HHCS 5/8-18 X 2 GR 8 1
25 042547 FSTN, HHCS, 3/4-10 X 1 1/4" LONG 4
26 043269 FSTN, NUT STOVER 5/8-18 2
27 044129 FSTN, NYLON NUT 3/4-10 2
28 045922 FTG, F6400-4-6-O STR JIC-SAE 2
29 047354 FSTN, HHCS 5/8-18x2-1/4 GR8 YZPLT 1
30 047973 BLADE, 8 X 23 FLAT FINISH 6
31 048385 ORIFICE, FOR L/R STEERING CYL CFJ4-043 1
32 048628 PIN, YOKE ARM 1
33 048659
PITCH CYLINDER HDX SERIES 3" BORE 1 1/2"
STROKE
1
34 049537 PLATE, PRESSURE 6 BOSS HDX740 1
35 049539 SPIDER ASSEMBLY, RH HDX740 1
36 049543 STABILIZER RING HDX740 1
37 049599 BEARING CAP HDX740 1
38 049697 BEARING HDX740 SPIDER ASSEMBLY 1
39 049708 WASHER, HD RETAINING 1
