allen HP205 - Page 51

064355 - 06/2017
Page 51
SECTION 4
PARTS
RH Rotor Module Assembly (cont’d)
Parts List
ITEM
PART
NO.
DESCRIPTION QTY
39 048659 PITCH CYLINDER HDX SERIES 3" BORE 1 1/2" STROKE 1
40 049537 PLATE, PRESSURE 6 BOSS HDX740 1
41 049538 SPIDER ASSEMBLY LH SOM HDX750 1
42 049543 STABILIZER RING HDX740 1
43 049599 BEARING CAP HDX740 1
44 049697 BEARING HDX740 SPIDER ASSEMBLY 1
45 049708 WASHER, HD RETAINING 1
46 050700 KEY, HDX740 ROTOR 1
47 052927 FTG, HYD F6502-8-8 1
48 053223 KEY, 3/16 X 1/4 X 2 1
49 053385 THROTTLE BRKT 1
50 055380 FSTN, HHCS 3/4-10 X 1 3/4" GR. 8 YELLOW ZINC 2
51 056775 AK30X1 1/8 1
52 056906 ENGINE CONNECTING PLATE 1
53 056912 HYDRAULIC PUMP MNTG PLATE WMNT 1
54
058757 KEY, 1/4 X 3/4" LONG
1
55
059513 SPACER F/ CLUTCH, MSP445
2
56
059776 FSTN, FW 3/4" GRADE 8 YELLOW ZINC
4
57
066253 BEARING ASSEMBLY FOR HP205
4
58
060865 WASHER, LARGE OD
1
59
060870 HHCS, 7/16-20 X 3/4
1
60
061234 ROD END
1
61
063930 BELT, CVT
1
62
064574 SCR, 7/16-20x4-1/2 YZ GR 8 HHC
1
63
064592 STUD, 3/4-10 X 4
2
64
064595 CYL MNT PLATE WMNT, RH
1
65
064614 GEARBOX, LH
1
66
064655 ENGINE MNT, GEARBOX HOUSING
1
67
064656 CROSSHEAD WELDMENT, L,R & F&R
1
68
065116 PITCH YOKE ARM FOR HP205
1
69
065825-1 ENGINE, KOHLER ECH980
1
70
065876 MUFFLER, RH
1
71
065907 BELT, 3L230
1
72
065967 PULLEY, HP205, DRIVER
1
73
066107 PULLEY, HP205
1
96
064591 LOWER BELT GUARD
1
