allen HP205 - Page 59

064355 - 06/2017
Page 59
SECTION 4
PARTS
LH Rotor Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
2 010024 FSTN, HHCS 5/16-18 X 2 GR 5 24
8 010090 FSTN, LW 5/16 24
12 015677 RING, Ø7/16 E-STYLE RETAINING 2
13 015691 FSTN, SHCS 1/2-13 X 1-1/2 RH 1
14 015693 PLUG, PLASTIC CAP EC12 1
15 015694 PLUG W-1 RED PLASTIC TAPERD 6
20 025091 FSTN, 3/8 SHOULDER BOLTx1/2 LONG 6
26 043269 FSTN, NUT STOVER 5/8-18 2
29 047354 FSTN, HHCS 5/8-18x2-1/4 GR8 YZPLT 1
30 047973 BLADE, 8 X 23 FLAT FINISH 6
32 048628 PIN, YOKE ARM 1
34 049537 PLATE, PRESSURE 6 BOSS HDX740 1
35 049539 SPIDER ASSEMBLY, RH HDX740 1
36 049543 STABILIZER RING HDX740 1
37 049599 BEARING CAP HDX740 1
38 049697 BEARING HDX740 SPIDER ASSEMBLY 1
39 049708 WASHER, HD RETAINING 1
40 050700 KEY, HDX740 ROTOR 1
47 060865 WASHER, LARGE OD 1
53 064613 GEARBOX ASSEMBLY, RH 1
57 065116 PITCH YOKE ARM FOR HP205 1
