allen HP205 - Page 6

064355 - 06/2017
Page 6
Table of Contents - Continued
Title Page
Section 4 - Parts
Factory Service Information 42
Replacement Part Procedure 43
Seat Frame Assembly 44
Right Rotor Module Assembly 48
Right Rotor Assembly 52
Left Rotor Module Assembly 54
Left Rotor Assembly 58
Right Spider Assembly 60
Left Spider Assembly 61
Fuel System Assembly 62
Spray System Assembly 64
LH Gearbox Assembly 68
RH Gearbox Assembly 70
Throttle Pedal Assembly 72
Kill Switch Pedal Assembly 74
Throttle System Assembly 76
Hydraulics Assembly 78
Mainframe Assembly 82
Electrical Schematics 86
Section 5 - Accessories
Front Dolly Jack Assembly 92
Rear Dolly Jack Assembly 94
Trowel Arm Alignment Jig Assembly 96
Accessories 98
