Page 71
SECTION 4
PARTS
RH Gearbox Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010068 FSTN, HHCS 1/2-13 X 1-1/4 GR 5 8
2 010069 FSTN, HHCS 1/2-13 X 1-1/2 GRADE 8 8
3 010071 FSTN, HHCS 1/2-13 X 2-1/4 GR 5 8
4 010093 FSTN, LW 1/2 GR8 24
5 012953 PLUG, 3/4 NPTF BI SQ HD PIPE 3
6 013484 SCR, 10-24x1/2 RDH PPH 3
7 013740 FSTN, LW STAR #10 3
8 015672 GAUGE, 3/4-14 NPT PORTHOLE VIEW 1
9 015673 O-RING, 15/16x1-3/16x1/8 BUNA 1
10 018510 FITTING, 1/4-28 NPT 45° GREASE 1
11 029179 SEAL, Ø1.375 RADIAL SHAFT OIL 2
12 029180 SEAL, Ø1.875 RADIAL SHAFT OIL 1
13 029529 VALVE, RELIEF 1/8-27NPT (AIR V) 1
14 032714 RING, RETAINING Ø2.4780 2
15 032715 RING, Ø2.857 RETAINING 1
16 041546 CASE, GEARBOX 600 SERIES 1
17 041578 FAN, 600 SERIES GEARBOX 1
18 041579 COVER, FAN 600 SERIES GEARBOX 1
19 041580 COVER, TOP ASSEMBLY 600 SERIES 1
20 041581 COVER, BOTTOM ASSEMBLY 600 SERIES 1
21 041583 CAP, FLANGE ASSEMBLY 600 SERIES 2
22 061300 SHAFT, 2" LH MAIN FOR XHD CR MAIN SHAFT ASSEMBLY 1
23 061222 GEARBOX RING WMNT 1
24 041561 CONE, BEARING 600 SERIES GEARBOX 2
25 064615-C SHAFT, LH WORM 1
26 029183 BEARING, Ø2 BORE TAPERED 2
27 029146 KEY, GEARBOX SQ 1/2x2.500 1
28 041559 SPACER, MAINSHAFT ASSEMBLY 1
