allen HP205 - Page 73

064355 - 06/2017
Page 73
SECTION 4
PARTS
Throttle Pedal Assembly - 064255
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010002 FSTN, HHCS 1/4-20 X 3/4 4
2 010020 FSTN, HHCS 5/16-18 X 1 1
3 010100 FSTN, NUT HEX 5/16-18 1
4 010131 PIN, Ø1/16 X 1 ZP STL COTTER 2
5 012361 PIN, Ø1/8 X 1 COTTER 2
6 024631 SWITCH, KILL FOR RIDING TROWEL 1
7 024839 ASSY, FOOT SPEED PEDAL 1
8 024851 THROTTLE HOUSING WMNT 1
9 024981 EXTENSION SPRING 1
10 024982 FSTN, PIN CLEVIS 1/4 X 51/64 2
11 024983 FSTN, PIN CLEVIS 3/8 X 3-1/4 1
12 028895 FSTN, PIN CLEVIS 3/8 X 3 3/4 1
13 040246 SHACKLE 1-1/4” FOOT SPEED SHORT 2
14 041596 WELDMENT, KILL SWITCH PLATE 1
15 059534 FULCRUM WMNT 1
