allen HP205 - Page 77

064355 - 06/2017
Page 77
SECTION 4
PARTS
Throttle Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 064654 ROTOR ASSEMBLY, RH 1
2 064651 ROTOR ASSEMLY, LH 1
3 064255 FOOT PEDAL W/ THROTTLE, RH 1
4 020542 FSTN, NUT STOVER LOCK 1/4-20 10
5 010002 FSTN, HHCS 1/4-20 X 3/4 GR8 10
6 010081 FSTN, FW 1/4 16
7 032301 CABLE, THROTTLE 72” HD 2
8 028243 CABLE, THROTTLE 52” HD 2
NOTE:
Not all parts are listed. Drawing needs to be updated to include all
parts of assembly.
