allen HP205 - Page 79

064355 - 06/2017
Page 79
SECTION 4
PARTS
Hydraulics Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
- 001002 OIL, HYDRAULIC 46 (DTE25) 2.5
1 045915 FTG, F6400-6-6-O STR JIC-SAE 2
2 045921 FTG, F6400-8-8-O STR JIC-SAE 2
3 045922 FTG, F6400-4-6-O STR JIC-SAE 2
4 045923 FTG, F6801-4-6-NWO 90° ELB JIC-SAE 6
5 045928 FTG, F6400-4-4-O STR JIC-SAE 8
6 045948 FITTING, 7574051 MAGNETIC PLUG 1
8 046732 SUCTION STRAINER TMF-02-06 1
9 064511 JOY STICK CONTROL, RIGHT HAND 1
10 064510 JOYSTICK LH 1
11 066151 PUMP, HYDRAULIC PLP10.3,15DO-30SO-LO 1
12 046777 FTG, F6400-6-4-O STR JIC-SAE 3
13 046892 FTG, 6801-6-6-NWO 90° ELB JIC-SAE 1
14 048659 CYLINDER, PITCH X1 2
15 048661 CYLINDER, 1.5x1.25 STEERING 3
18 052902 FITTING, HYDRAULIC 6409-8 1
19 052906 HOSE, HYD HS-455-1 (8M3K) 1
20 052907 HOSE, HYD HS-455-2 (8M3K) 1
21 052908 HOSE, HYD HS-455-3 (6M3K) 1
22 052909 HOSE, HYD HS-455-4 (6M3K) 1
23 052910 HOSE, HYD HS-455-5 (6M3K) 1
24 052911 HOSE, HYD HS-455-6 (4M3K) 1
25 052912 HOSE, HYD HS-455-7 (4M3K) 1
26 052913 HOSE, HYD HS-455-8 (4M3K) 1
27 052914 HOSE, HYD HS-455-9 (4M3K) 1
28 052915 HOSE, HYD HS-455-10 (4M3K) 1
29 052916 HOSE, HYD HS-455-11 (4M3K) 1
30 052917 HOSE, HYD HS-455-12 (4M3K) 1
31 052918 HOSE, HYD HS-455-13 (4M3K) 1
33 052926 FTG, HYD SMK20-7/16UNF-VE TEST PORT 1
34 052927 FTG, HYD F6502-8-8 1
37 053334 HOSE, OIL DRAIN F/ MSP445 1
39 056932 GAUGE 76MM 3” LEVEL GAUGE 1
41 066150 MANIFOLD ASSY, STEERING PITCH 1
