SECTION 4
PARTS
Mainframe Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010002 FSTN, HHCS 1/4-20 X 3/4 GR8 10
2 010019 FSTN, HHCS 5/16-18 X 3/4 GR 5 8
3 010035 FSTN, HHCS 3/8-16 X 3/4 18
4 010036 FSTN, HHCS 3/8-16 X 1 7
5 010081 FSTN, FW 1/4 16
6 010085 FSTN, FW 1/2 GR8 24
7 010090 FSTN, LW 5/16 2
8 010091 FSTN, LW 3/8 18
9 010100 FSTN, NUT HEX 5/16-18 4
10 010102 FSTN, NUT HEX 3/8-16 4
11 010109 FSTN, NUT HEX NYLON 5/16-18 4
12 010464 FSTN, NUT NYLOK 3/8-16 11
13 010568 SCR, 10-32 X 1/2 RND HD MACH 8
14 010632 FSTN, HHCS 5/8-11 X 2 GR 8 6
15 011238 FSTN, NUT HEX NYLOK 1/2-13 12
16 012612 FSTN, NUT HEX NYLOCK 5/16-18 12
17 012702 TIP, 80°x0.10 GPM BRASS SPRAY 2
18 012994 RIVET, 1/8x3/8 ALUM DOME HD [closed] 4
19 016382 SCR, 10-32 X 3/8 SLTD RDH MACH 4
20 018072 WSHR, #10 Z STL SAE FLAT 4
21 020036 THROTTLE CABLE, 72" 1
22 020542 FSTN, NUT STOVER LOCK 1/4-20 10
23 020688 FSTN, JAM HEX NUT 5/8-18 RH 1
24 023003 FSTN, HHCS 1/2-13 X 4 12
25 028243 THROTTLE CABLE, 52" 1
26 029568 NUT, 10-32 NYLOCK HEX 12
27 032097 DECAL, SERIAL NUMBER PLATE 1
28 033735 PUMP, SPRAY SYSTEM 1
29 033900 THROTTLE CABLE CONNECTOR, HP105 1
30 033914 PLATE, THROTTLE MOUNT, HP105 1
31 037139 FSTN, NUT NYLOC 5/8-18 GR 8 6
32 037771 BATTERY, 12 V GRAY 655CA 1
33 039329 FSTN, CLIP TINNERMAN 1/4-20 4
34 040030 HOSE BARB FITTING, 1/4" X 1/8" 1
35 040209 FILTER, RETARDANT SPRAY SYSTEM 1
36 040387 ELBOW, 3/8 BRASS 90° STREET 1
37 040388 FTG, 3/8x1/4 BRASS FM-TO-MALE 1
38 041624 RETAINER, NYLON SPRAY TIP 2
39 042140 BRACKET, REAR LIGHT SP400B 2
40 042260 LATCH, T-HANDLE EXTRA-LARGE DRAW 2
41 042343 FSTN, SFBHCS 1/4"-20 x 3/4 4
44 045922 FTG, F6400-4-6-O STR JIC-SAE 6
45 046242 FILTER GAUGE, GV-10 1
46 046731 SIGHT GLASS HYD RESERV. 1
47 047274 CUSHION F/ BATTERY PLATE 1
48 047700 TANK, 6 GALLON WATER PLASTIC 1
49 047715 ROD, 5/16-18 BATTERY RETAINER 8-5/8" 2
50 047933 ELBOW, 1/4 PUSHLOKx1/4 NPT PLASTIC 1
51 048299 OIL,GEARBOX 2
52 048385 ORIFICE, FOR L/R STEERING CYL CFJ4-043 3
53 048653 BARB, HOSE PLASTIC 1/4" x 1/4 NPT 3
54 048661 CYLINDER, 1.5x1.25 STEERING 3
55 048665 TUBE, MANUAL PACK PLASTIC 9000-14 1
54 041606 PLASTIC 1/4 NPT CLOSE NIPPLE 2
55 041624 RETAINER, NYLON SPRAY TIP 2
