allen HP205 - Page 85

064355 - 06/2017
Page 85
SECTION 4
PARTS
Mainframe Assembly (cont’d)
Parts List
ITEM PART NO. DESCRIPTION QTY
57 048921 STRAP, TANK MSP425 8
58 048932 BAR, BATTERY HOLD DOWN 1
59 049957 NOZZLE BODY MALE STRAIGHT CP8028-NYB 2
60 053189 U-BOLT, 3 1/2" X 3/8-16 2
61 053200 TANK ASSY, 6 GAL FUEL W/ CAP (EPA) 2
62 059535 FOOT PEDAL W/ KILL, LH 1
63 064255 FOOT PEDAL W/ THROTTLE, RH 1
64 066251 LIFTING PLATE, REAR 1
65 064621 DECK WMNT. 1
66 064622 FRONT PANEL WMNT. 1
67 066250 LIFTING PLATE, FRONT 1
68 064651 ROTOR ASSEMLY, LH 1
69 064654 ROTOR ASSEMBLY, RH 1
70 064663 MAIN FRAME WMNT. 1
71 064688 STEP F/ FRAME 2
72 064701 SPRAYER BRKT 2
73 064749 LIGHT, LED 4
74 065023 ADAPTER, 6410-20-08 1
75 065024 PLUG, 6408-HHP-20 1
76 065039 FRONT COVER PLATE 1
77 065172 ELECTRIC FUEL PUMP, 40178 1
78 065173 FACET INLINE FILTER, 479735 1
79 065174 Y CONNECTOR, 1/4" HOSE 2
80 065175 CHECK VALVE F/ SPRAY SYSTEM 2
81 065244 STRAINER, POLY 100 µ MESH, W/ CHECK VALVE 2
82 065652 780 DECAL "GREASE THRUST BEARINGS 2
83 065653 780 DECAL "LIFT HOOK" 4
84 065654 780 DECAL "ALLEN MADE IN USA" 1
85 065655 780 DECAL "RETARDANT ONLY" 1
86 065656 780 DECAL "PAN FALL" 2
87 065657 780 DECAL "OPERATOR'S MANUAL" 1
88 065875 MUFFLER, LH EXHAUST 1
89 065876 MUFFLER, RH EXHAUST 1
90 066018 DECAL, GAS ONLY (7.75 X 2.5) 2
91 066067 DECAL, HYDRAULIC FLUID HP205 1
92 066072 DECAL, FRONT STRIPE HP205 1
94 029568 NYLOC NUT, 10-32 2
95 051542 SHCS, 10-32 X 3/4 1
110 066188 5/8" FEMALE ROD END 3
111 065446 ROD, END MALE 5/8 3
112
048681 GROMMET, RUBBER 5/8 ID X 1-1/8 OD 2
