allen HP205 - Page 93

SECTION 5
ACCESSORIES
064355 - 06/2017
Page 93
Front Dolly Jack Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 010133 PIN, 3/16 X 2 COTTER 2
2 010464 FSTN, NUT NYLOK 3/8-16 4
3 015692 CAP, Ø1/4 RED GREASE 2
4 017751 FSTN, FW HARD A325 3/8 (p) 8
5 024628 SPACER, DOLLY JACK 4
6 026729 LIFT, FRONT DOLLY JACK 2
7 026938 JACK, SP DOLLY 1
8 039633 DECAL, DOLLY JACK SYSTEM 1
9 040637 BOLT, 3/8-16 X 2-1/4 GR 8 HHC 4
10 099014 ASSY, 410/350 X 4 PNEU WHEEL 2
