064355 - 06/2017
Page 97
SECTION 5
ACCESSORIES
Trowel Arm Alignment Jig Assembly
Parts List
ITEM PART NO. DESCRIPTION QTY
1 015884 SCREW, 3/8-16x1 SCKT CAP 4
2 016877 FSTN, SHCS 3/8-16 X 1-1/2 3
3 028076 SCREW, 3/8-16x2 SCKT CAP 2
4 028981 BASE 1
5 028982 CLAMP, BLOCK 1
6 028983 ARM 1
7 028984 SPACER, 2.600 HGT ADJUSTING 1
8 028985 WASHER 1
9 028986 SPACER, 2.243 HGT ADJUSTING 1
10 029474 SPACER, 2.500 HGT ADJUSTING 1
11 047426 SPACER, 2.725 HGT ADJUSTING 1
