Exhaust Requirements

Part No. 70458301ENR7

Duct Station Eco Line 025

Classic Line 025

and all 030 Series

035, 055 and

T30 Series T45 Series

G 14 in. (356 mm) 19 in. (483 mm) 23 in. (584 mm) 28 in. (711 mm)

H 14 in. (356 mm) 20 in. (508 mm) 24 in. (610 mm) 30 in. (762 mm)

I 15 in. (381 mm) 22 in. (559 mm) 26 in. (660 mm) 32 in. (813 mm)

J 16 in. (406 mm) 23 in. (584 mm) 27 in. (686 mm) 33 in. (838 mm)

K 17 in. (432 mm) 24 in. (610 mm) 28 in. (711 mm) 35 in. (889 mm)

L 18 in. (457 mm) 25 in. (635 mm) 30 in. (762 mm) 36 in. (914 mm)

Table 4

NOTE: Table 4 represents units with the same vent

size. If multiple vent sizes are used, consult a local

HVAC specialist.

NOTE: Duct clean-out recommended every 6 feet

(183 cm) .
