Specifications and Dimensions
30
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 70458301ENR7
Gas Connection – CE and Australian Units
Models A B C
55 Series 59 in. (1,500 mm) 2.5 in. (64 mm) 35 in. (889 mm)
Gas Connection – Non-CE and Non-Australian Units
Models A B C
25 Series 57 in. (1,450 mm) 2.5 in. (64 mm) 35.5 in. (927 mm)
30 Series 57 in. (1,450 mm) 2.5 in. (64 mm) 43 in. (1,092 mm)
35 Series 57 in. (1,450 mm) 4 in. (101.6 mm) 43 in. (1,092 mm)
55 Series 55.285 in. (1,404 mm) 1.621 in. (41.17 mm) 46.75 in. (1,187.45 mm)
