Operation
11
F8112201
PHM1398C
1 Stop Button 7 Infra-Red Programming Port
2 Start Button 8 Enter Button
3 Main Display 9 Temperature/Toggle Button
4 Program Number/Alarm Display 10 Up Button
5 Emergency Stop Button 11 Down Button
6 Run/Program Mode Key Switch 12 Number Buttons
Figure 3
