Step Test Cycle Step Display Description
2 Display Software Version XXX.YY XXX is the display cargo ver-
sion number and YY is the dis-
play cargo subversion number.
3 I/O Board Software Version XXX.YY XXX is the control software
version number and YY is the
control software subversion
number.
4 Drive Software Version Drive: XXX
Fan: YYY
XXX is the drive motor soft-
ware version number. YYY is
the fan motor software version
number.
5 ICM Software Version XXX XXX is the control software
version number.
6 Control Level MXXX XXX is the control level.
7 Dip Switch Switches that are up and green
are ON and switches that are
down and red are OFF.
This test displays the current
dip switch settings.
8 Capacity TXX, FXX or XXX XX or XXX is the capacity in
pounds.
9 Keypad The digit for each keypad will
show in a grid.
Unpressed keypads will have
black fill, pressed keypads will
have white fill.
10 Display - This test will display a se-
quence of patterns.
12 Door Switch Test "Door Switch Test", “Open” or
“Closed”
The display will show “Door
Switch Test” and the switch
state, “Open” or “Closed”.
13 Lint Door Test "Lint Door Test", “Open” or
“Closed”
The display will show “Lint
Door Test” and the switch state,
“Open” or “Closed”.
14 Heat Configuration "Heat Configuration" and
"Electric Heat", "Steam
Heat", "Gas Domestic" or
"Gas EU"
Temperature: XXY
XX is the temperature and Y is
the units (Celsius or Fahren-
heit).
15 Moisture Sensor Test #1 "Moisture Test #1", "Result:
Pass"/ "Result: Open", "A2D:
XXX" and "Time: YY"
XXX is the value read from the
analog moisture sensor input
and YY is the time.
16 Moisture Sensor Test #2 "Moisture Test #2", "Result:
Pass"/ "Result: Open", "A2D:
XXX" and "Time: YY"
XXX is the value read from the
analog moisture sensor input
and YY is the time.
Table 11 continues...
