press the keypad to return and run the test again. If either the
loading or lint doors are opened during the test, the control will
reset the test step and allow it to be run again. When the test is
complete and the result is displayed, the control sounds a 5 sec-
ond audio signal.
The display will show "Moisture Test #2", "Result: Pass"/"Result:
Open", "A2D: XXX" and "Time: YY" where XXX is the value
read from the analog moisture sensor input and YY is the time.
The control will advance to the next step when the keypad is
pressed.
Diagnostics Menu
©
