Clothes Do Not Dry in Dryer
Does heater assembly
not heat or burner
not ignite?
Is there too much
water in articles
being dried?
No
Refer to Dryer
Heating Assembly Does
Not Heat or Burner
Does Not Ignite
flowchart.
Yes
Is laundry load too
large?
No
Remove excess water
by re-spinning in
washer.
Yes
Is laundry load too
small?
No
Remove part of load.
A normal washer load
is a normal dryer
load. Maximum load:
Dryer cylinder one
half full of wet
clothes.
Yes
Is there excessive
lint on lint filter?
No
Add one or two bath
towels to load.
Yes
Is exhaust system
improper or
inadequate?
No
Clean lint filter.
Yes
Does heater assembly
or burner shut off
prematurely?
No
Refer to Installation
Instructions
(supplied with unit)
for exhaust
requirements.
Yes
Gas Models: Is gas
line pressure too
high or too low?
No
Refer to Dryer Heater
Assembly or Burner
Shuts Off Prematurely
paragraph.
Yes
Is belt installed
improperly (low RPM -
correct RPM is 52 ±
1)?
No
If Natural Gas line
pressure to dryer
exceeds 10.5 inch
water column
pressure, or is lower
than 5 inch water
column, ask Gas
Company to correct.
Yes
Check for proper
installation.
Yes
Dryer Troubleshooting
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
30 Part No. D515519R3
