ALLIANCE STEBXASP434AW12 User Manual

Motor Will Not Start
NOTE: Checks to be made only if motor does not start and “door” is not diplayed on control. If “door” is dis-
played please refer to door open troubleshooting.
(1)
Is there voltage
across terminals 5
and 4 of the motor?
(2)
Is there voltage
across H3-4 and H3-6
on the control?
No
Replace the motor.
Yes
(3)
Is there voltage
across H3-5 and H3-3
on the control?
No
Correct the wiring to
the motor.
Yes
Refer to door open
troubleshooting.
No
Replace the I/O
control.
Yes
Electronic Control Troubleshooting
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
43 Part No. D515519R3
