ALLIANCE STENXASP543DN01 - Coins Ignored When Entered

Coins Ignored When Entered
Start Production Test Cycle and advance to Coin Drop step.
Does the count on the
display increment
properly after
entering coins?
Is "H11" connector
properly seated on
the control board?
No
Reset control to
ready mode.
Yes
From the coin drop,
is the 3-pin
connector properly
plugged in?
Yes
Properly reseat
connection and
conduct diagnostic
test again.
No
Are the wires exiting
the coin drop optical
sensor cracked or
broken?
Yes
Properly reseat
connection and
conduct diagnostic
test again.
No
Replace electronic
control.
No
Replace the coin drop.
Yes
Electronic Control Troubleshooting
©
