Electronic Control Troubleshooting
48.Will Not Heat – Steam – OPL Microprocessor (continued)
TMB1835S
Correct wiring
between cabinet
limit and terminal 5
of fan motor
centrifugal switch.
Is there voltage to the
input of the cabinet
limit?
Replace cabinet
limit.
Is there voltage to
output of cabinet limit?
Correct wiring
between stove limit
and cabinet limit.
Is there voltage to input
of stove limit?
Replace stove limit.
Is there voltage to the
output side of the stove
limit?
Replace or rebuild
steam valve.
Does the steam valve
operate properly?
Check for proper
steam supply.
Correct if necessary.
Is heat produced?
Continued from column 2 of
previous page.
NO
YES
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
Correct wiring to
steam valve coil.
NO
Is there voltage across
steam valve coil?
YES
UNIT
OPERATIONAL.
