Clamp

Open

Gauge Post

Figure 4-12, Hose connections

To cylinder

base end

To cylinder

base end

To cylinder

rod end

To cylinder

rod end

To truck

supply

(close) V1

To truck

supply

(open) V2

To truck

secondary

(side shift)

Figure 4-13, Hose connections

Open Forks Port V2

Close Forks Port V1

Figure 4-14, Hose connections
