Allied Systems LONG REACH FLN Series User Manual

45-009 REV. 8/20
36
6.9 Reusable Hose Fittings
Kit hoses equipped with reusable fittings allow hoses to be cut to the exact length
required for installation.
NOTICE
Do not shorten hoses to the point where they
will be stretched or kinked when installed.
Make sure hoses are not pinched, rubbed, twisted,
or otherwise damaged throughout their full range of
movement. Use hose clamps to secure hoses if necessary.
6.9.1 Remove Fitting
To shorten a hose, remove the reusable end-fitting using the following procedures:
1. Clamp the fitting socket in a vise.
Fitting
Socket
Fitting
Insert
2. Unscrew the fitting insert from the fitting socket.
3. Unscrew the hose clockwise from the fitting socket.
