Allied Systems W6F User Manual

3
General
13
8
3
2
6
5
7
7
4, 9
12
11
1
10
14
15
1. Drum
2. Access Cover for Filter
3. Access Cover to Hydraulic Valve
4. Access Cover to Hydraulic System
5. Plug to Check Oil Level
6. Plug to Drain Oil
7. Tie Rod
8. Fill Plug
9. Cover for Oil Brake
10. Intermediate Shaft Bearing Retainer
& Freespool Adjuster *
11. Drum Shaft Bearing Retainer
12. Drawbar
13. Breather
14. Serial Number Stamped (New)
15. Serial Number Stamped (Old)
* NOTE: Exterior freespool adjust mechanism available
as standard only on AW6F-4062 and above.
Older winches may be fi tted with the exterior
adjustment mechanism as well.
Figure 1 - W6F Towing Winch

Allied Systems W6F Specifications

General

Brand	Allied Systems
Model	W6F
Category	Winches
Language	English
