Allied Systems W6F - Recommended Oils and Capacity

6
Recommended Oil List and Oil Capacity
The type of oil used in Allied winches affects the line
control. Use the following oils in the W6F winch:
Figure 4 - Recommended Oil List
°F °C
ExxonMobil Mobil Fluid 424 (Factory fill) -13 to 105 -25 to 43
John Deere Hy-Gard™ -13 to 122 -25 to 50
Chevron 1000 THF -13 to 105 -25 to 43
Caterpillar Multipurpose Tractor Oil (MTO) -13 to 104 -25 to 40
Case Hy-Tran Ultra -20 to 122 -30 to 50
°F °C
ExxonMobil Mobil Fluid LT -40 to 86 -40 to 30
John Deere Low Viscosity Hy-Gard -40 to 86 -40 to 30
Chevron THF W -40 to 86 -40 to 30
* Note: Use of non-recommended oils may void warranty.
Recommended Oils* - General Conditions
Ambient Temperature Range
Recommended Oils* - Low Temperature Conditions
Ambient Temperature Range
Manufacturer Oil Type
Manufacturer Oil Type
Winch Model Oil Capacity
W6FP - Standard 16.5 Gal (62.5L)
W6FP - with Dropbox 17 Gal (64.5L)
Figure 4.1 - Oil Capacity
