30
INTERVAL PROCEDURE OR QUANTITY SPECIFICATION
50 hours or weekly Check oil level at plug (item 2). Add oil as
necessary through fi ll plug (item 5). Check
winch oil level with engine off and tractor on
level ground.
See Figure 4, Recommended Oil List.
Check winch control lever (cable controls). See
Figs. 12, 13 & 14.
Use SAE 30 oil on the linkage if
needed. Check that the control cable
and control housing are fastened
correctly. Tighten U-bolts if required.
Clean the breather (item 6). Remove debris around breather.
Lubricate the rollers on the fairlead assembly, if
the winch is so equipped.
Use multi-purpose grease with 2-4%
molybdenum disulfi de.
250 hours or monthly There may be a gear box fastened to the front
of the winch which has a separate oil reservoir.
If this gear box lowers the Input shaft of the
winch, then the oil level in this gear box must
be checked and fi lled independently of the main
winch.
Fill to proper level if low. If oil level
cannot be checked, add 1/2 quart. See
Figure 11-1 for details.
500 hours or every 3
months
Clean the oil suction screen and magnets.* Use a new gasket between the cover and
the suction tube.
Clean the breather. Remove debris around breather.
Replace the fi lter.* See the Parts Manual for fi lter element
and cover gasket. When replacing, be
sure to lubricate fi lter seal ring between
element and fi lter head.
(Continued on next page)
Figure 11 - Maintenance Schedule
