Allied Systems W6F - Winch Unit Identification System

8
Unit Identifi cation
Allied Winch S/N Nameplate Data For Tractor Mountings
A W6F P 1 N 1501 C71
Manufactured By
Vehicle Code
Sequence Number
Internal Options
Winch Model
Drive Type
Gear Ratio Code
A = Allied Systems Company
(no "A" = Hyster Company)
P = Power Controlled
X = Direct Drive
See Figure 6
M = Horizontal Control Lever, Non-FREESPOOL
(For Direct Drive Only)
F = FREESPOOL
N = Vertical Control Lever, Non-FREESPOOL
U = Underwind Drum
In Addition to the serial number plate,
the serial number is stamped on to the
left hand side of the frame.
Circled numbers in Figure 6 indicate
possible gear ratios.
2.
NOTES: 1.
W6F = Standard
K6F or KW6F = Special Product Engineering Design
Gear Code = Forward Ratio / Reverse Ratio
1 = 45.14:1 / 19.47:1 (Komatsu PS 81.69:1 / 35.24:1)
2 = 56.36:1 / 24.31:1 (Komatsu PS 101.99:1 / 43.99:1)
3 = 64.90:1 / 28.10:1
4 = 81.00:1 / 35.00:1
5 = 44.00:1 / 19.00:1
6 = 106.36:1 / 45.88:1
7 = 27.90:1 / 12.10:1
8 = 85.19:1 / 36.75:1
9 = 55.61:1 / 45.88:1
