Allied Telesis AT-GS950/48PS - Front and Back Panels

Chapter 1: Overview
18
Front and Back Panels
Figure 1 illustrates the front panels of the AT-GS950/10PS, AT-GS950/
16PS, and AT-GS950/48PS Gigabit Ethernet Switches.
Figure 1. AT-GS950/10PS, AT-GS950/16PS, and AT-GS950/48PS Front
Panels
AT-GS950/16
AT-GS950/48PS
AT-GS950/16PS
10/100/1000Base-T
SFP Slots
Twisted Pair Ports
AT-GS950/10PS
eco-Friendly
Button
Port and
System LEDs
eco-Friendly
Button
SFP Slots
Port and
System LEDs
eco-Friendly
Button
10/100/1000Base-T
Twisted Pair Ports
SFP Slots
System LEDs
eco-Friendly
Button
10/100/1000Base-T
Twisted Pair Ports
