Allied Construction Products, LLC Technical Manual Ho-Pac 300, 300B & 500, 500B
9
SECTION 5.0
TECHNICAL INFORMATION
5.1 SPECIFICATIONS
Table 5.2
General Specifications
Model
500
Impulse Force
3,940 [17,530]
Lbs [N]
Cycles Per Minute
2000
1/min
Sound Power Level
105 [Est’d]
DBA [LWA]
Hydraulic Flow
(a)
Motor
Option
1
9 [34]
gpm
[lpm]
2
14 [53]
3
18 [68]
Max Operating
Pressure
Motor
Option
1
2800 [193]
psi
[bar]
2
2500 [172]
3
2000 [138]
Oil Pressure @ No Load
300-500 [20-35]
Auxiliary Circuit
Relief Pressure
Dynamic
(b)
Max Operating + 400 [28]
Static
Max Operating + 650 [45]
Compaction Plate Dimensions (Std)
12 x 27 [305 x 686]
Inch [cm]
Compaction Area (Std)
2.3 [0.21]
Ft
2
[m
2
]
Compaction Plate Dimensions (Opt)
18 x 22 [457 x 559]
Inch [cm]
Compaction Area (Opt)
2.8 [0.26]
Ft
2
[m
2
]
Hose Size
Pressure
5/8 [16]
Inch
[mm]
Return
(c)
5/8 [16]
Weight
(d)
XSF
513 [233]
BSF
513 [233]
Lbs
[kg]
Flat-Top
XR
498 [226]
XCS / BCS
491 [223]
Carrier Weight
(e)
Excavator
3-12 [1.4-5.5]
Lbs (1,000)
[kg] (1,000)
(a)
For optimal Ho-Pac operation, the carrier’s auxiliary hydraulic circuit must be capable of providing the
specified oil flow at a pressure equal to at least the dynamic relief pressure. Proper selection of the Motor &
Valve Package is critical to ensure efficient machine operation.
(b)
Verify the carrier’s main relief is set to the manufacturer’s specifications and that this value is equal or greater
than the dynamic relief setting.
(c)
Return line pressure (measured at the Ho-Pac) in excess of 150 psi [10 bar] will decrease service life of
motor.
(d)
Working weight with typical mounting kit/bracket.
(e)
Mount only to carriers having adequate load-carrying capabilities.
