Allied Construction Products, LLC Technical Manual Ho-Pac 300, 300B & 500, 500B
36
PARTS INFORMATION – 300, 300B (cont’d)
Table 12.2
Model 300 & 300B - Mounting Frame & Hydraulics
Item
Part No.
Description
Qty
Remarks / Specifications
---
572740C
Ho-Pac 300 (Fig. 5-1)
---
Configured with XSF Mounting Frame
---
572730C
Ho-Pac 300 (Fig. 5-2)
---
Configured with IN1 & IN2 / XR Mounting
Frame
---
573453C
Ho-Pac 300B (Fig. 5-1)
---
Configured with XSF Mounting Frame
---
573220C
Ho-Pac 300B (Fig. 5-2)
---
Configured with IN1 & IN2 / XR Mounting
Frame
1a
572830
Top Mounting Frame
1
XSF Mounting Family
1b
572829
Top Mounting Frame
1
Flat Top IN1 & IN2 / XR Mounting Family
2a
572736
300 Dynamic Assembly
1
See separate figure and parts list
2b
573223
300B Dynamic Assembly
3
Varies
Motor
1
See Table 12.1 for GPM options
4
Varies
Elbow
1
See Table 12.1 for Elbow
5
Varies
Elbow
1
See Table 12.1 for Elbow
6
572831
Hose Assembly
1
Pressure Line (P2)
7
573534
Hose Assembly
1
Return Line (T1)
8
677119
Adapter
2
9
Varies
Valve
1
See Table 12.1 for options
10
813290
Hex Head Cap Screw
2
3/8”
11
813292
Flat Washer
2
3/8”
12
759808
Elastic Nut
2
3/8”
13
102699
Elbow
2
45
o
14
101418
Hose Assembly
2
72”
15
677179
Adapter
2
---
670006
Q.D. Coupler Set
1 (Set)
Set includes 16, 17
16
670007
Quick Disconnect
1
Socket
17
670008
Quick Disconnect
1
Plug
18
818676
Pressure ID Tag
1
Located on pressure hose
---
Varies
Mounting Pins (not shown)
---
See Table 6.2 for separate figure and parts
list.
