PARTS INFORMATION - 300
Table 12.3
Model 300 Dynamic Assembly
Item
Part No.
Description
Qty
Remarks / Specifications
---
572736
Dynamic Assembly & Suspension - Model 300
1
572737
Lower Assembly
1
2
572739
Eccentric Assembly
1
3
572828
Bearing Housing
1
4
902538
Hex Head Cap Screw
6
5
798190
Lock Washer
6
6
572738
Bearing
2
7
572719
Socket Head Cap Screw
2
8
708514
Flat Washer
2
9
572827
O-Ring
1
10
102694
Gasket
1
11a
714721
Rubber Spring Mount
4
Former spring 714721 is discontinued.
Replaced by spring kit part no. 574582
(a)
11b
574574
Follow Figure 12-4b for proper arrangement
of hardware
12a
102490
Bushing
4
Required on slotted frames
12b
572080
Lock Washer
4*
½” (* Pair). Slotted frames require only 4
pair.
13a
102491
Hex Nut
8
Not used with newer spring
13b
574341
Hex Head Cap Screw
8
Torque to 80 ft/lbs [108 Nm]
14
90444
Flange Plug
2
15
A102780
Relief Plug
1
16
Varies
Motor
1
See Table 12.1 for GPM options
a)
Spring mount kit, 574582 includes 1-Spring 574574, 2-HHCS 574341, 2 (Pair) Washers 572080
