Allied Construction Products, LLC Technical Manual Ho-Pac 300, 300B & 500, 500B
40
PARTS INFORMATION – 300B (cont’d)
Table 12.4
Model 300B Dynamic Assembly
Item
Part No.
Description
Qty
Remarks / Specifications
1-13
573223
Dynamic Assembly & Suspension - Model 300B
1
573224
Lower Assembly
1
2
573225
Eccentric Assembly
1
3
573312
Bearing Housing
1
4
902538
Hex Head Cap Screw
6
5
798190
Lock Washer
6
6
573260
Bearing
2
7
572719
Socket Head Cap Screw
2
8
708514
Flat Washer
2
9a
714721
Rubber Spring Mount
4
Former spring 714721 is discontinued.
Replaced by spring kit part no. 574582
(a)
9b
574574
Follow Figure 12-5b for proper arrangement
of these parts
10a
102490
Bushing
4
Required on slotted frames
10b
572080
Lock Washer
8*
½” (* Pair). Slotted frames require only 4
pair.
11a
102491
Hex Nut
8
Not used with newer spring
11b
574341
Hex Head Cap Screw
8
Torque to 80 ft/lbs [108 Nm]
---
Varies
Motor
1
See Table 12.1 for GPM options
a)
Spring mount kit, 574582 includes 1-Spring 574574, 2-HHCS 574341, 2 (Pair) Washers 572080
