Allied Construction Products, LLC Technical Manual Ho-Pac 300, 300B & 500, 500B
42
PARTS INFORMATION - 500
Table 12.5
Model 500 - Mounting Frame & Hydraulics
Item
Part No.
Description
Qty
Remarks / Specifications
---
570317C
500 Ho-Pac (Fig. 5-3)
---
Configured with XR Mounting Frame
---
102684C
500 Ho-Pac (Fig. 5-4)
---
Configured with XCS / BCS Mounting
Frame
---
100924C
500 Ho-Pac (Fig. 5-5)
---
Configured with BSF Mounting Frame
---
102685C
500 Ho-Pac (Fig. 5-6)
---
Configured with XSF Mounting Frame
1a
570312
Top Mounting Frame
1
“XR” Mounting Family
1b
A102686
Top Mounting Frame
1
“XCS / BCS” Mounting Family
1c
102811
Top Mounting Frame
1
“BSF” Mounting Family
1d
102687
Top Mounting Frame
1
“XSF” Mounting Family
2
102693
Dynamic Assembly
1
See separate figure & parts diagram
3
Varies
Motor
1
See Table 12.1 for GPM options
4
Varies
Adapter
1
See Table 12.1 for adapter
5
Varies
Elbow
1
See Table 12.1 for elbow
6
102700
Hose Assembly
1
Pressure Line (P2)
7
102701
Hose Assembly
1
Return Line (T1)
8
677119
Adapter
2
9
Varies
Valve
1
See Table 12.1 for options
10a
814213
Hex Head Cap Screw
2
3/8” x 3 1/2" XR & XCS/BCS Frames
10b
813290
3/8” x 4” XSF & BSF Frames
11
759808
Hex Nut
2
For use on XSF & BSF Frames
12
813292
Flat Washer
2
13
102699
Elbow
2
45
o
14
101418
Hose Assembly
2
72”
15
677179
Adapter
2
