Allied Construction Products, LLC Technical Manual Ho-Pac 300, 300B & 500, 500B
48
PARTS INFORMATION - 500
Table 12.7
Model 500 Dynamic Assembly & Suspension
Item
Part No.
Description
Qty
Remarks / Specifications
---
102693
Dynamic Assembly & Suspension
1
572572
Eccentric Housing
1
Configured with Weld-on Compaction Plate
2
102690
Eccentric
1
3
102691
Eccentric Shaft
1
4
102692
Bearing Housing
2
5
708621
Hex Head Cap Screw
8
6
708512
Flat Washer
8
7
714714
Bearing
2
8
714715
Cover Plate
1
9
708513
Hex Head Cap Screw
6
10
708514
Flat Washer
8
11
714717
Spacer
1
12
563446
Socket Head Cap Screw
2
13
102694
Gasket
1
Motor
14
102695
Gasket
2
Bearing Housing
15
A102697
Gasket
1
Bearing Cover
16a
714721
Rubber Spring Mount
4
Former spring 714721 is discontinued.
Replaced by spring kit part no. 574885
(a)
16b
574885
Follow Figure 12-8b for proper arrangement
of hardware
17a
102490
Spring Mount Bushing
4
Used with slotted frames
17b
572080
Lock Washer
4*
(* Pair) Not used on busing side
18a
102491
Hex Nut
8
Used with former spring
18b
573341
Hex Head Cap Screw
8
Torque to 80 ft/lbs [108 Nm]
19
A102780
Pressure Relief Plug
1
20
656775
Socket Head Plug
2
a)
Spring mount kit, 574885 includes 1-Spring 574574, 2-HHCS 574884, 1-(Pair) Washer 572080
