Allied Construction Products, LLC Technical Manual Ho-Pac 300, 300B & 500, 500B
50
PARTS INFORMATION
Table 12.8
Model 500B Mounting Frame & Hydraulics
Item
Part No.
DESCRIPTION
Qty
Remarks / Specifications
---
573440C
500B Ho-Pac (Fig. 5-7)
1
Configured with XSF Mounting Frame
---
573320C
500B Ho-Pac (Fig. 5-8)
1
Configured with Flat Mounting Frame
1a
573441
Top Mounting Frame
1
Mounting Family “XSF”
1b
573316
Top Mounting Frame
1
Mounting Family IN1 & IN2 / XR
2
573317
Dynamic Assembly
1
See separate figure and parts list
3
Varies
Motor
1
See Table 12.1 for GPM options
4
Varies
Elbow
1
See Table 12.1 for part number
5
Varies
Elbow
1
See Table 12.1 for part number
6
573646
Hose Assembly
1
Pressure Line
7
573645
Hose Assembly
1
Return Line
8
677119
Adapter
2
9
Varies
Valve
1
10
813290
Hex Head Cap Screw
2
3/8”
11
813292
Flat Washer
2
3/8”
12
759808
Hex Nut
2
3/8”
13
102699
45
o
Elbow
2
45
o
14
101418
Hose Assembly
2
72”
15
677179
Adapter
2
---
670006
Q.D. Coupler Set
1(Set)
Set includes 16, 17
16
670007
Quick Disconnect
1
Socket
17
670008
Quick Disconnect
1
Plug
18
818676
Pressure ID Tag
1
Located on Supply Hose
---
Varies
XSF Mounting Kit
1
See Table 6.2 for list of mounting kits
