508228-01 Issue 2136 Page 13 of 41
COMPRESSOR
HARNESS
CONNECTION
LIQUID LINE SERVICE VALVE
SUCTION LINE SERVICE VALVE
OUTDOOR COIL
DISCHARGE LINE
HIGH PRESSURE SWITCH
COMPRESSOR
GROUND LUG
CONTACTOR
CONTROL
DUAL RUN
CAPACITOR
CONTROL WIRE
LOOP
CUTOUT FOR HIGH
VOLTAGE CONDUIT
NOTE — Plumbing layout and compressor type may vary between model sizes.
CRANKCASE HEATER
THERMOSTAT
CRANKCASE HEATER
THERMAL SWITCH
Figure 1. Typical Parts Arranegment
