Allied 4AC16L - Technical Specifications - 4 AC14*P-6 Thru 7

508228-01Issue 2136Page 10 of 41
MODEL NUMBER GUIDE
Technical Specications - 4AC14*P-6 thru 7
Minor Revision Code
Major Revision Code
Electrical
P - 208 - 230v/60hz/1Ph
Tonnage
18, 24, 30, 36, 41, 42, 47, 48, 59, 60
Restrictions
Blank = Standard Model
R = Region-Restricted Model, not for
installation in the Southwest region
Refrigerant
4 = R410A
AC
Air Conditioner
SEER
14
Tier
L = Louvered
B = Wire Guard
4 AC 14 L R 24 P - 7 A
PHYSICAL AND ELECTRICAL DATA
Model
Voltage/Hz/
Phase
Voltage
Range
Min.
Circuit
Amp.
Max. Over
Current
Device
(amps)
Compressor Fan Motor
Refrig.
Charge
(oz.)
Rated
Load
(amps)
Locked
Rotor
(amps)
Rated
Load
(amps)
Rated HP
Nom.
RPM
4AC14*18P-6,7
208-230/60/1 197-253 12.4 20 9.4 56.6 0.7 1/0 1075 77
4AC14*R18P-6,7
4AC14*24P-6,7
208-230/60/1 197-253 15.0 25 11.2 60.8 1.0 1/6 825 86
4AC14*R24P-6,7
4AC14*30P-6,7
208-230/60/1 197-253 17.0 25 12.8 67.8 1.0 1/6 825 100
4AC14*R30P-6,7
4AC14*36P-6,7
208-230/60/1 197-253 18.6 30 14.1 83.0 1.0 1/6 825 102
4AC14*R36P-6,7
4AC14*41P-6,7 208-230/60/1 197-253 22.6 35 16.7 79.0 1.7 1/4 825 161
4AC14*42P-6,7
208-230/60/1 197-253 24.1 40 17.9 113.0 1.7 1/4 825 160
4AC14*R42P-6,7
4AC14*47P-6,7 208-230/60/1 197-253 26.7 45 19.9 109.0 1.8 1/3 825 179
4AC14*48P-6,7 208-230/60/1 197-253 26.6 45 19.8 109.0 1.7 1/4 825 174
4AC14*59P-6,7 208-230/60/1 197-253 34.1 50 25.0 134.0 2.8 1/3 825 178
4AC14*60P-6,7 208-230/60/1 197-253 34.8 60 26.4 134.0 1.8 1/3 825 192
