REFRIGERATION DATA
Outdoor Model
Charge
(oz)
6
Refrigerant Connection
Refrigerant Line Size
Indoor Expansion
Device
Outdoor Indoor (DTC)
7
Suction Liquid Suction Liquid Suction Liquid Piston TXV
1
4AC16L18P-50 73 3/4 3/8 3/4 3/8 3/4 3/8 0.052 H4TXV01
4AC16L24P-50 73 3/4 3/8 3/4 3/8 3/4 3/8 0.060 H4TXV01
4AC16L30P-50 88 3/4 3/8 3/4 3/8 3/4 3/8 0.067 H4TXV01
4AC16L36P-50 113 7/8 3/8 7/8 3/8 7/8 3/8 0.072 H4TXV02
4AC16L41P-50 144 7/8 3/8 7/8 3/8 7/8 3/8 † H4TXV02
4AC16L42P-50 140 7/8 3/8 7/8 3/8 7/8 3/8 0.081 H4TXV02
4AC16L47P-50 176 7/8 3/8 7/8 3/8 7/8 3/8 † H4TXV02
4AC16L48P-50 156 7/8 3/8 7/8 3/8 7/8 3/8 0.083 H4TXV02
4AC16L59P-50 189 7/8 ** 3/8 7/8 3/8 1-1/8 3/8 † H4TXV03
4AC16L60P-50 192 7/8 ** 3/8 7/8 3/8 1-1/8 3/8 0.097 H4TXV03
*Factory charged for 15 feet of line set
** Adapter shipped with unit
† TXV only
COOLING PERFORMANCE WITH DTC
1
Outdoor Model Indoor Model
Capacity
(BTUH)
EER SEER
4AC16L18P-50 EAC4X24B 18,000 12.20 14.00
4AC16L24P-50 EAC4X24B 24,000 12.20 14.25
4AC16L30P-50 EAC4X30B 28,400 12.20 14.00
4AC16L36P-50 EAC4X36B 34,000 12.20 14.25
4AC16L41P-50 EAC4X49C 38,000 12.20 14.00
4AC16L42P-50 EAC4X49C 40,000 12.20 14.00
4AC16L47P-50 EAC4X60C 46,000 12.20 14.00
4AC16L48P-50 EAC4X60C 46,000 12.20 14.00
4AC16L59P-50 EAC4X60C 56,000 11.70 14.00
4AC16L60P-50 EAC4X60C 58,000 11.70 14.00
1
DTC = Designated Tested Combination
NOTE:
For the latest ratings, please see
www.alliedratings.com or www.AHRIdirectory.org
