Allied A80US2V - Page 34

508155-01Issue 2108Page 34 of 49
Figure 21. A80US2V NO
X
Inserts
Remove 5 screws if necessary
(either side of cabinet)
1
2
3
4
5
Figure 22.
heat exchanger
gasket
collector box
orifice plate
flue transition
pressure switch
combustion air inducer
burners
burner box cover plate
manifold and gas valve
gasket
retention rings
cross over
rollout switches
(alternate location)
rollout switch
rollout switch
Figure 23. A80US2V Burner, C.A.I. Assembly, and Heat Exchanger Removal
