Allied A96US2V - Blower Performance Data (Models 090); A96 US2 V090 C12 S Blower Performance

507404-02 Page 53 of 80Issue 1448
HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 1210 1300
+18% 1150 1240
+12% 1090 1175
+6% 1035 1115
Fauctory Default 975 1050
-6% 915 990
-12% 860 925
-18% 800 860
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 605 745 855 965 880 1045 1210 1375
Factory 550 675 775 875 800 950 1100 1250
- 495 610 700 785 720 855 990 1125
A96US2V090C12S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 1425 1580
+18% 1355 1505
+12% 1290 1430
+6% 1220 1350
Fauctory Default 1150 1275
-6% 1080 1200
-12% 1010 1120
-18% 945 1045
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 770 935 1075 1240 1100 1320 1540 1760
Factory 700 850 975 1125 1000 1200 1400 1600
- 630 765 880 1015 900 1080 1260 1440
A96US2V090C16S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
